C50 1:1 Stub pump

Eurolube’s air operated pumps are designed for the most demanding operations. Unique pre-lubricated air motor design, lubricator NOT required. Quiet and double acting operation and easy to fit to drum or tank, 2” drum adapter included

Technical data

Part No

B11741

Ratio

1:1

Capacity

40 l/min free flow

Air connection

1/4" (F) BSP

Maximum air pressure

1,0 (10) MPa (bar)

Inlet

1" (F) BSP

Outlet

3/4" (F) BSP

Pump tube

52 (212) Ø (length) mm

Seals

NBR/PU

Packaging LxWxH

0,53 x 0,1 x 0,1 m

Weight (Gross)

3 kg

H.S. Code

84135069

Downloads

• B11740_B11741.pdf
